Interface: 1 x RJ45 Serial Port
16 x 10/100/1000 RJ45 Ports
2 x 1/10 Gbps SFP+ Ports
Buttons: Reset
Power Supply: Max. Power Consumption: 40W (Excludes PoE Output)
Power Input: 1 x DC Terminal Block or 2 x RJ45 (Ports 1 and 2) (Self-Correcting Polarity Protection on DC Terminal Block Only, Diode ORed Protection on All Power Inputs)
Power Supply: Min. 54V / 0.8A (Excludes PoE Output Power)
VDC Input: 54V DC, 6A
Passive PoE Input: (2) 54V / 1.5A, 4-Pair (+1, 2, 4, 5; -3, 6, 7, 8) Passive PoE, Ports 1 and 2 (Do NOT Configure Port 1 or 2 in PoE Output Mode if You Are Using PoE Input Power Sources.)
Passive PoE Output:
(4) 54V or 24V / 1.4A, 4-Pair (+1, 2, 4, 5; -3, 6, 7, 8) Passive PoE, Ports 1 to 4
(12) 802.3af/at or 24V / 0.7A, 2-Pair (+4, 5; -7, 8) Passive PoE, Ports 5 to 16
Power Monitoring:
1 x DC Terminal Block, Input Power
2 x RJ45, Ports 1 ...
