ASUS Pro WS W680-ACE IPMI Intel W680 LGA 1700 ATX workstation motherboard, dual PCIe 5.0x16 slot, DDR5, ECC memory and XMP support, dual Intel 2.5 Gb Lan, 3xPCIe 4.0 M.2 slots, USB 3.2 Gen 2x2 front panel connector, SlimSAS.

Name: ASUS Pro WS W680-ACE IPMI Intel W680 LGA 1700 ATX workstation motherboard, dual PCIe 5.0x16 slot, DDR5, ECC memory and XMP support, dual Intel 2.5 Gb
Brand: ASUS
SKU: N82E16813119617
Rating: 3 (3 reviews)

(3)(2) Write a Review

Intel LGA 1700 socket: Ready for 13th Gen Intel Core processors & 12th Gen Intel Core, Pentium® Gold and Celeron® Processors
Enhanced power solution: DrMOS, ProCool connector, alloy chokes and durable capacitors for stable power delivery
Next-gen connectivity: Dual PCIe 5.0 Safeslots, dual PCIe 3.0 slots, 3 x M.2 PCIe 4.0, SlimSAS, dual Intel 2.5Gb Ethernet, front panel USB 3.2 Gen2x2 Type-C, Thunderbolt 4 header support, TPM header, LPT header.
Comprehensive cooling: Large VRM heatsink, M.2 heatsinks, hybrid fan headers and Fan Xpert 4
Advanced security management: USB port management, software blacklisting and Regedit on/off controls via ASUS Control Center Express
Trusted stability: Tested for 24/7 operation, validated for extensive compatibility and equipped with SafeSlot and SafeDIMM for enhanced durability
Bundle with IPMI Expansion card, equips with a dedicated Ethernet controller to BMC chip to provide the intelligence for its IPMI architecture

Overview

Specs

Reviews (3)

Pro WS W680 ACE IPMI

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Limited Warranty period (parts): 3 years
Limited Warranty period (labor): 3 years
Read full details

Return Policies

Return for refund within: 30 days

Return for replacement within: 30 days

This item is covered by Newegg.ca's Standard Return Policy.
Read full return policy for details.

CPU Socket Type	LGA 1700
CPU Type	Celeron / Intel Core 12th Gen (LGA 1700) / Intel Core 13th Gen (LGA 1700) / Pentium Gold

Number of Memory Slots	4x288pin (DDR5)
Memory Standard	DDR5 4400
Maximum Memory Supported	128GB
Channel Supported	Dual Channel
Memory Feature	ECC and Non-ECC Un-buffered Memory* Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) OptiMem II * Supported memory types, data rate(Speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list. * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

PCI Express 5.0 x16	Intel 13th & 12th Gen Processors* - 2 x PCIe 5.0 x16 slots (support x16 or x8 / x8 mode) * Please check the PCIe bifurcation table at the support site (https://www.asus.com/support/FAQ/1037507/).
PCI Express 3.0 x16	Intel W680 Chipset - 2 x PCIe 3.0 x16 slots (supports x4 mode)
PCI Express x1	1 x PCIe 3.0 x1 slot

Serial ATA (SATA)	8 x SATA 6Gb/s
M.2	Intel 13th & 12th Gen Processors - M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) Intel W680 Chipset - M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) - M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) Intel Rapid Storage Technology supports Intel® Optane Memory H Series on PCH attached M.2 slots.
SATA RAID	0/1/5/10

LAN Chipset	2 x Intel 2.5Gb Ethernet ASUS LANGuard
Max LAN Speed	2.5Gbps
Wireless LAN	M.2 slot only (Key E, CNVi & PCIe)* * Wi-Fi module is sold separately.

ASUS Pro WS W680-ACE IPMI Intel W680 LGA 1700 ATX workstation motherboard, dual PCIe 5.0x16 slot, DDR5, ECC memory and XMP support, dual Intel 2.5 Gb Lan, 3xPCIe 4.0 M.2 slots, USB 3.2 Gen 2x2 front panel connector, SlimSAS.

Learn more about the ASUS Pro WS W680-ACE IPMI

Customer Reviews of the ASUS Pro WS W680-ACE IPMI

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

Onboard USB	1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports
Other Connectors	Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin W_PUMP+ header 3 x 4-pin Chassis Fan headers Storage related 3 x M.2 slots (Key M) 4 x SATA 6Gb/s ports 1 x SlimSAS port Miscellaneous 1 x LPT header 1 x T-sensor 1 x Clear CMOS header 1 x COM Port header 1 x BMC Header 1 x Front Panel Audio header (AAFP) 1 x Start button 1 x Flexkey button 1 x SPI TPM header (14-1pin) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x M.2 slot (Key E) 1 x LPT_P80 Switch 1 x Thunderbolt header

Form Factor	ATX
Dimensions (W x L)	12.0" x 9.6"
Power Pin	1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector 1 x 4-pin +12V Power connector 1 x 6-pin PCIe Power connector
