WPA – Personal WPA– Enterprise WPA2 – Personal WPA2 – Enterprise 64/128-bit WEP SSID Broadcast Disable MAC Address Access Control
Frequency Band
2.4GHz to 2.4835GHz 5.15GHz to 5.25GHz and 5.725GHz to 5.85GHz
Antenna
Dipole Antenna
Transmitted Power
18dBm @ 2.4 GHz 17dBm @ 5 GHz
Interface
Ethernet Port
LEDs
Power 5GHz LAN 2.4GHz
Power Supply
48VDC +/- 10% for PoE or 5V 2.5A
Environmental
Temperature
0°C - 40°C (32°F - 104°F)
Humidity
10% - 90% (Non-Condensing)
Dimensions & Weight
Dimensions
7.8" x 4.8" x 1.3"
Weight
0.9 lbs.
Features
Features
User-Selectable 2.4GHz or 5GHz Frequency Band Operation for Increased Network Capacity 802.3af PoE Support 3 Dipole Antennas to Boost Signal Strength Operable as Wireless Client, Access Point (Wireless Connectivity for Computers), WDS (Wireless Bridge), or WDS with AP Multiple SSID, 802.1Q VLAN WMM (Wireless QoS) Automatic Channel Selection
