Fluke Networks 19800009 TS19 Telephone Test Set with Angled Bed-of-Nails Clips

Shop All FLUKE networks Products

Fluke Networks 19800009 TS19 Telephone Test Set with Angled Bed-of-Nails Clips

Name: Fluke Networks 19800009 TS19 Telephone Test Set with Angled Bed-of-Nails Clips
Brand: FLUKE networks
SKU: N82E16899708058
Price: 250.99 CAD
Availability: InStock
Rating: 5 (1 reviews)

(1) Write a Review

Detects dial tone and polarity, places and receives calls during testing of telephone lines
High impedance DataSafe operation in monitor mode
Tone (DTMF) and pulse operation
Last number redial
Polarity indication in talk mode

Overview

Specs

Reviews (1)

The TS19 Test Set combines all the essential test set features at a value price. The TS19 Test Set was specifically designed for in-house telecom technicians.Its high-impedance monitor prevents accidental disruption of service from clipping onto a data line while in monitor mode, thus ensuring the integrity of critical data lines. Features such as tone (DTMF) or pulse operation, talk/monitor capabilities, polarity test button and last number redial make this test set the perfect combination of features and price.

Warranty & Returns

Warranty, Returns, And Additional Information

Return Policies

We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between October 7, 2024 and December 31, 2024 you will have until January 31, 2025 to return your product.

Return for refund until: January 31, 2025

Return for replacement until: January 31, 2025

This item is covered by Newegg.ca's Extended Holiday Return Policy. Read full return policy for details.

Quantity	No
Specifications	Electrical Loop Limit 2.4 kOmaximum at 48 VDC (nominal 15 mA minimum loopcurrent) DC Resistance (Talk Mode) 150 Otypical at 80 mA current AC Impedance (Monitor Mode) Low impedance (Ring position) 600 Oat 1 KHz typical High impedance (HI Z position) 100 kOminimum at 1 KHz Rotary Dial Output 10 pps .5 pps Pulsing Rate 60 % ± 2 % Percent Break 800 ms typical Interdigit Interval Leakage During Break > 50 kO DTMF Output ±1 % maximum Tone Frequency Error Level per Tone Pair dBm maximum, - dBm minimum High versus Low Tone Difference 4 dB maximum Physical Length 8.75 in (22.2 cm) Width 2.375 in (6.03 cm) Height 3.375 in (8.57 cm) Weight 10.8 oz (.307 kg) maximum Environmental Temperature Operating: -5 °C to °C Storage: -40 °C to °C Drop 1 meter, 4 times Altitude To 3,000 meters (10,000 feet) maximum Relative Humidity 10 %to 80 % (non-condensing) Regulatory Standards Used 47 CFR Part 15, Subpart B ICES-003 Issue 3 AS/NZS 3548 EMC Directive 89/336/EEC, EN 55022:98, EN 61326:97, A1:98 Annex C, EN 61000-4-2, EN 61000-4-3 LV Directive 73/23/EEC, EN 610010.1 (1993) Certifications and Compliance Conformité Européenne. Conforms to relevant European Union directives. CAN/CSA-C22.2 No. 60950-1-03 CAN/CSA-C22.2 No. 1010.1-92 CSA-C22.2 No. 1010.1B-97, UL/ANSI 3111-1
