Learn more about the GAMEMAX VP-700-RGB-M
GeneralBrand | GameMax |
---|
Model | VP-700-RGB-M |
---|
DetailsColor | Black |
---|
Maximum Power | 700 W |
---|
Fans | 1 x 120 mm |
---|
Fan LED | RGB |
---|
PFC | Passive |
---|
Main Connector | 20+4Pin |
---|
PCI-Express Connector | 2 x 6+2-Pin |
---|
SATA Power Connector | 5 |
---|
Max PSU Length | 150 mm |
---|
Modular | Semi-Modular |
---|
Efficiency | > 80% |
---|
Energy-Efficient | Efficiency Level 80+ Bronze |
---|
Over Voltage Protection | Yes |
---|
Overload Protection | Yes |
---|
Protection | OPP, OVP, UVP, OCP, OTP, SCP |
---|
Input Voltage | 100 - 240 V |
---|
Input Frequency Range | 50/60 Hz |
---|
Input Current | 12-6.3A |
---|
MTBF | >100,000 Hours |
---|
Approvals | Safety and Environmental Safety and EMC CB, CCC,CE |
---|
Dimension & WeightDimensions | 140 mm (W) x 150 mm (L) x 86 mm (H) |
---|
Weight | 2 KG |
---|
Output+3.3V Max. Current | 20A |
---|
+5V Max. Current | 20A |
---|
+12V1 Max. Current | 48A |
---|
-12V Max. Current | 0.5A |
---|
+5VSB Max. Current | 2.5A |
---|
FansFans Total Quantity | 1 |
---|
Top Fans Size | 120mm |
---|
Top Fans Bearing Type | Fluid Dynamic Bearing |
---|
Top Fans LED | RGB |
---|
ProtectionOver Voltage Protection | Yes |
---|
Over Load Protection | Yes |
---|
Short Circuit Protection | Yes |
---|
Under Voltage Protection | Yes |
---|
Over Current Protection | Yes |
---|
Over Power Protection | Yes |
---|
Over Temperature Protection | Yes |
---|
Additional InformationDate First Available | July 20, 2023 |
---|
