4K@60Hz HDMI Video Capture Card with Mic & 3.5mm Audio 1080p 60fps Board Game Capture Card USB3.0/Type-C Recorder Box Device for Live Streaming Video Recording Loop Out

USB 3.0 Capture Card 1080p 60fps: 4K capture card is designed with high-end smart chip and made of Aluminum Alloy. With high-speed USB 3.0 technology, game capture card makes it no delay and makes the live streaming, sharing and recording simple and fast. Supports HDMI input resolution up to 4K@60Hz and record video signal up to 1080p 60fps for the game video and streaming media with a high-quality and glitch-free experience.
Features
Support MJPEG and YUY2;
Support UAC & UVC agreement, support 48 KHz PCM audio sampling rate;
Some win7 need to install the driver;
Compatible with Windows 7, 8, 8.1, 10 or later, Linux OS, Mac OS operating systems;
Can automatically detect the input video format, and automatically adjust to the set output size and frame rate;
Can automatically detect the input audio format and convert it to 48KHz PCM audio;
2 collection rods can be used on a PC;
Support online firmware upgrade to better improve product compatibility;
the delay is better;

Capture Card USB 3.0, 4K HDMI Video Capture Card to USB/Type-C with Microphone & HDMI Loop-Out, Capture Card 1080p 60fps for Streaming, Compatible with Nintendo Switch/Game Console/Phone

USB 3.0 Capture Card 1080p 60fps: 4K capture card is designed with high-end smart chip and made of Aluminum Alloy. With high-speed USB 3.0 technology, game capture card makes it no delay and makes the live streaming, sharing and recording simple and fast. Supports HDMI input resolution up to 4K@60Hz and record video signal up to 1080p 60fps for the game video and streaming media with a high-quality and glitch-free experience.
No delay HDMI Loop-Out: Our hdmi video capture card has an HDMI OUTPUT port which support hdmi loop-out live video up to 4K@60fps. There is no delay and you could enjoy it when you are making a game live streaming with your friends.
3.5mm Microphone Input & Audio Output: Provide microphone input and audio output, standard 3.5mm audio microphone can realize online live streaming audio and video recording. You can also connect the audio video capture device to your headphone with 3.5.mm audio out port.

Product specification
Input interface: 1 HDMI interface;
Output interface: USB3.0, 300 ~ 350MB / s throughput;
HDMI input: 4K / 60Hz, 1080P / 60, 59.94, 50, 30, 29.97, 25, 24, 23.98, 1080i 50/60, 720P 50 / 60,480P, 576P1280x1024, 1280x960, 1024x768, 800x600, 640x480
HDMI sound input: LPCM sound signal;
HDMI input format: compatible with HDMI 2.0 standard, maximum bandwidth support 225MHz 4K / 60Hz, 12bit deep color;
Video sampling rate: HDMI: 165MHz;
Software compatibility: Adobe Flash Media Live Encoder (Windows, OS X); Real Producer Plus (Windows); VLC (Windows, OS X, Linux); QuickTime Broadcaster (OS X); QuickTime Player (OS X), OBS, PotPlayer and etc.

Plug and Play

This HDMI video capture card has no drivers to install and leverages the capabilities already built into current software for a seamless experience. Compatible with most software, just plug and play in Windows, Mac OS X and Linux with no guesswork needed.

Wide Compatibility

USB 3.0 capture card compatible with Windows, Mac OS X and Linux and other operating systems. Compatible with Nintendo Switch, PlayStation 3/4, Xbox One, Switch, Wii U, camera and pretty much any other consoles. Be real-time streaming on Twitch / YouTube / OBS Studio / Potplayer / Facebook more easily with your gameplay.
