4K Android 9.0 TV Box Amlogic S905D 1GB 8GB FTA DVB-T2 Digital TV Tuner Combo H.265 HEVC DVB-S2 Ccam Satellite TV Receiver DVB-C

4K Android 9.0 TV Box Amlogic S905D 1GB 8GB FTA DVB-T2 Digital TV Tuner Combo H.265 HEVC DVB-S2 Ccam Satellite TV Receiver DVB-C

Model

A1 Pro_OTT&S\S2\S2X+T/T2+C

Hardware

CPU

Amlogic S905D Quad Core ARM Coretex-A53  Up to 2.0GHz(DVFS) (Optional S912)

GPU

Penta-Core ARM Mali-450 Up to 750MHz+(DVFS)

RAM

DDRIII 1GB

EMMC  Flash

EMMC Flash 8GB

WiFi

802.11 b/g /n

Blutooth

NO

IR

IR Infra Remote control

LED Indicator

Red LED Standby,Blue LED Run

DVB-T/T2  Demodulation

DVB-T/T2

DVB_T2 System standard :ETSIEN 302 755

Support MPLP

Demodulation: QPSK,16QAM,64QAM or 256QAM

Forward error correction rate 1/2,2/3,3/4.3/5,5/6

Guard interval:1/4,19/256;1/8,19/128;1/16,1/32,1/128

Bandwith 6/7/8MHz

Input Frange range:54--860MHz lnput lmpedance:75

Input Signal levl:-84 dBm to 0 dBm(average power)

DVB-S/S2 Demodulation

DVB-S/S2

DVB-S\S2  system standard

Forward error correction rate 1/2,2/3,3/4.3/5,5/6.8/9,9/10

Input RF Frequency:950MHz to 2150MHz

Code Rates: 1/2, 2/3, 3/4, 5/6, 7/8

FFT Mode:2k,8k

Symbol Rates::1- 55 Msps

DVB-C

Receiving FrequencyVHF174~230MHz/UHF 470~862MHz

Waveform : CDFDM

Bandwith:  6/7/8MHz

Demodulation:QPSK,16QAM,64QAM

Guard Modes Interval :1/32,1/16,1/8,1/4

Mode : 2K/8K

CAS

Support cccam newcamd biss powervu tandberg

Operating System

Android 9.0 OS

Video  Decoding

VP9 Profile-2 up to 4K*2K@30fps

H.265 HEVC MP-10@L5.1 up to 4K*2K@30fps

H.264 AVC @L5.1 up to 4K*2K@30fps

Audio  Decoding
