2020 New HOT 10/100/1000M PCI-E PCI Express to 4x Gigabit Card 4 Port Ethernet Network Adapter

100% brand new and high quality

Standard Compliant

PCI express base SPEC 2.0 and backward compatible with SEPC 1.1 & 1.0a

PCI Power management SPEC 1.2

Supports 10/100/1000Mbps data rate auto negotiation operation

Supports PCI Express 1.1

Supports pair swap/polarity/skew correction

Crossover Detection & Auto-Correction

Wake-on-LAN and remote wake-up support

Microsoft NDIS5, NDIS6 Checksum Offload (IPv4, IPv6, TCP, UDP) and Segmentation

Task-offload (Large send v1 and Large send v2) support

Supports EMAC-393 ECMA ProxZzzy Standard for sleeping hosts

Supports Full Duplex flow control (IEEE 802.3x)

Supports jumbo frame to 9K bytes

Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Supports IEEE 802.1P Layer 2 Priority Encoding

Supports IEEE 802.1Q VLAN tagging

Supports IEEE 802.3az-2010 (EEE)

Supports power down/link down power saving/PHY disable mode Built-in switching regulator

Supports PCI (Message Signaled Interrupt) and -X

Supports quad core Receive-Side Scaling (RSS)

Supports Protocol Offload (ARP & NS)

Supports Four 1-Lane 2.5Gbps PCI Express Bus

Supports hardware ECC (Error Correction Code) function

Supports hardware CRC (Cyclic Redundancy Check) function

System Requirement: Windows 20000, ME, 98SE, Windows Server 2003/XP/Visit/ 2008/7 /8 32-/64-bit,Linux,MAC OS 10.4 or above and DOS.

Board Size(L*W):11.40*6.90cm/4.49"*2.72"

Quantity:1Set
