High Power 15A 400W MOS FET Trigger Switch Drive Module PWM Regulator Electronic Switch Control Panel DC 5V-36V

Origin:CN(Origin)
Model Number:15A 400W MOS FET Trigger Switch Drive Module

100% and
Material: Electrical components
Color: See pictures
Module Highlights:
1. The use of imported dual-MOS parallel active output, lower resistance, more current, strong power at room temperature, 15A, 400W, to meet the most use of the equipment
2. Wide voltage, the perfect support for PWM
3. Easily control high power devices
Product specifications and applications:
1: Operating Voltage: DC 5V - 36V;
2: The trigger source: digital high-low (DC3.3V - 20V), can be connected microcontroller IO port, PLC interfaces,
DC power, you can access the PWM signal, the signal frequency 0--20KHZ perfect support.
3: output capacity: DC DC 5V - 36V, at room temperature, continuous current 15A, power 400W! Lower auxiliary
cooling conditions, the maximum current up to 30A.
4: Applications: You can control the output of power equipment, motors, light bulbs, LED lights, DC motors, micro-pumps,
solenoid valves, etc., you can enter
PWM, motor speed control, lamp brightness.
5: Availability: unlimited switch; Operating temperature: -40-85 ;
Size: See the picture
Quantity:1Pc
No retail package
Note: Due to the difference between different monitors, the picture may not reflect  the actual color of the item. Thank you!!
Package Included:
1   x  15A 400W High-power MOS FET Trigger Switch Drive Module PWM Regulator Control Panel
