Origin:CN(Origin)
Certification:NONE
Model Number:150M USB WiFi Antenna
Feature:
Compliant with IEEE 801.11n IEEE 802.11g, IEEE 802.11b standard
1x1 / 1x2 mode
STBC supports extended range
Traditional and high throughput modes
20MHz / 40MHz bandwidth
Reverse data flow and frame aggregation
WEP 64/128, WPA, WPA2 support
Multiple BSSID support
Provide USB 2.0 high speed interface
Cisco CCX V1.0 V2.0 V3.0 Compliance
Low power, advanced power management
For Windows 7, Windows XP, Windows Vista and Windows 2000
Product Features:
Socket Adapter: USB 2.0 / 1.1
Interface type: USB
Application: Desktop
Frequency range: single frequency (2.4 GHz)
Type: Wireless
Type: External
Transmission rate: 150Mbps
Wireless protocol: 802.11b, 802.11g, 802.11n
Model: None
Specification:
Standard: IEEE 802.11g, IEEE 802.11b, CSMA / CA with ACK
Interface: USB2.0
Frequency range: 2.4GHz-2.4835GHz
Wireless data rate:
11N: 150/54/28/14/7/3 (adaptive)
11G: 54/28/14/7/3 (adaptive)
11b: 11 / 5.5 / 2 / 1M (adaptive)
Channel: 1~11 (US, Canada); 1~13 (Europe); 1~14 Japan
Spread Spectrum: DSSS
Modulation: BPSK, QPSK, CCK and OFDM (BPSK / QPSK / 16-QAM / 64-QAM)
Transmission distance: up to 100m indoors and up to 300m outdoors (limited to
surroundings)
Transmitting power: 15dBm
Antenna plus: 2X2dBi
LED indicator: status
Data security: WPA; 64/128-bit WEP; TKIP / AES
Environment: Working temperature: 0 ° C ~ 40 (32 ~ 104)
Working humidity: 10%~90% without condensation
Hot Tip: There is no CD driver for this property (you need to download the URL: //pan.baidu.com/s/19JXvC
Package Contents:
1 x 150M WIFI wireless adapter
