USB Audio Video Capture USB 2.0 Video Converter Convert Analog Video to Digital Format

USB2.0 UVC Video Capture for Win&Mac

A smart advanced device for Desktop and notebook users transfers analog signal video to digital signal, and edit their own home video on PC. No matter what AV & S-video video device like V8, VHS, HI8, even old videotapes - the image is easily sent to PC.

USB 2.0 UVC interface, no need to install any drivers on your computer, just plug into your computer's USB 2.0 port, and system will install drivers for you automatically, no matter your Windows OS or Mac OS.



For Windows OS

Includes VHS to DVD 3.0 software, it can edit and save on CD in VCD and DVD format. Provides high-quality video processor and compression solutions to allow video resolution up to 30fps @ 720x 480 (PAL/25fps @ 720 x 576) size in order. VHS to DVD 3.0 also can upload the video to your YouTube account.

Interface:USB 2.0 UVC standard

TV System:PAL, NTSC

Recording Format:MPEG2

Converting Format:AVI-MPEG4,AVI-DIVX,MP4-MPEG4(iPod),3GP-MPEG4,PSP-MPEG4 …

Input:Composite Video(RCA), S-Video(miniDIN 4pin), Audio L/R(RCA)

Resolution:NTSC 160×120~720×480, PAL 160×120~720×576

Rate:NTSC 30fps, PAL 25fps

Power Supply:USB Bus

Comsumed Power:=1.5W

Editing/Converting Software: Windows ArcSoft Showbiz3.5

Cable Length:80cm(USB), 7cm(Video/Audio)

Dimension / Weight·73(L)×30(W)×22(H)mm / 67g

Package Contents

Video Capture device, Software CD



System Requirements

One available USB 2.0 port

Pentium4 CPU or above

512MB RAM or above

Graphics card supports DirectX 9.0C

1GB free HDD space

CD-ROM for installation

DVD-R/RW for burning DVD

Windows XP, Vista, Seven



For Mac OS X

Includes?ezcap VideoGrabber?, it's a simple powerful software application that has everything you need to capture home video. The software features a simple storyboard view for basic video sequencing and more advanced timeline view giving you greater control over your movie clips, audio tracks, and transitional effects. ezcap VideoGrabber allows you to set the recording format for iPod, Then you can transfer the recording files to your iPod by iTunes.



Recording Format:Quick Time supports file formats

Capture Software: Mac OS Quicktime or OBS Studio(For Mac)

Input:Composite Video(RCA), S-Video(miniDIN 4pin), Audio L/R(RCA)



System Requirements

One available USB 2.0 port

Power Mac G4 or above, Intel Core Processor

512MB RAM or above

1GB free HDD space

CD-ROM for installation

(Update driver--- support Mac OS 10.14 64bit or later).
