AUTYUE 8K@60Hz Displayport KVM Switch 3 Monitors 2 Computers 4K@144Hz, DP USB 3.0 KVM Switch Triple Monitor for 2 PCs Share 3 Monitors, RJ45 Ethernet Splitter 1 to 2, Audio Mic Port and 3 USB 3.0 Port

• DP1.4 Displayport KVM Switch Triple Monitor for 2 PCs Share 3 Monitors, RJ45 Ethernet Splitter 1 to 2, Audio Mic Port and 3 USB3.0 Devices

You will get:

• 1x 8K@60Hz Triple Monitor KVM Switch,
• 2x USB 3.0 Cables,
• 1x Power Adapter,
• 1x Wired Button Switch,
• 1x User's manual.
• DP cables and Ethernet RJ45 cables are not included

• 1. Insert the DC/5V adapter into the KVM ;
• 2. Plug the Ethernet RJ45 cable into the KVM switch;
• 3. Plug the 3*DisplayPort cable into the KVM switch and monitor;(Output)
• 4. Plug the DisplayPort cable, Splitter Adapter Cable and USB cable into the KVM switch and your computer/laptop (DP cables are not included)(Input)
• DP IN 1A +DP IN 1B + DP IN 1C + USB IN 1 + RJ45=PC1
• DP IN 2A + DP IN 2B + DP IN 2C + USB IN 2 + RJ45=PC2
• Please check whether DP IN 1A, DP IN 1B, DP IN 1C, and USB IN 1 corresponding, and whether DP IN 2A, DP IN 2B, DP IN 2C and USB IN 2 are corresponding.
• Mixed insertion is not supported.
• 5. Insert the mouse and keyboard into the KVM switch
• 6. If needed, you can connect a microphone and audio port

• This RJ45 Ethernet Splitter KVM Switch can split one network cable into two outputs.
• Two computers can be connected to the Internet at the same time.
• Supports 1000 Mbps Gigabit Ethernet performance. RJ45 Ethernet Splitter connector extender is compatible with Cat67 Cat6 Cat5 Cat5e network ethernet cable.

• 3 Monitors KVM Switch DisplayPort: support resolution up to 8K@60Hz/4K@144Hz, and backward compatible with lower resolution.
• Note: that you can only get 8K if both your computer's graphics card and monitor support 8K.

Audio & Microphone Output:

Triple monitor KVM switches with 3 integrated USB 3.0 ports that can recognize keyboard, mouse, printer, scanner and other USB devices.

Supports ultra-fast USB 3.0 data transfer up to 5Gbps, backward compatible with USB 2.0/1.1 devices.

3 Monitor KVM also supports separate audio and microphone output.

Plug and play without any software needed.

• Triple monitor KVM switches with 3 integrated USB 3.0 ports that can recognize keyboard, mouse, printer, scanner and other USB devices.
• Supports ultra-fast USB 3.0 data transfer up to 5Gbps, backward compatible with USB 2.0/1.1 devices.

Audio & Microphone Output:

• 3 Monitor KVM also supports separate audio and microphone output.
• Plug and play without any software needed.

• Splicing Mode: Computer host outputs splice screens on 3 monitors.
• Extended Mode: PC host in output 3 different images on 3 monitors.
• Copy Mode: Computer host outputs 3 identical images on 3 monitors.
• (Note: Please make sure your computer supports multi-display and each connected computer requires 3 DP ports)
