PCIe Gen3 X14 to 24 Ports 6G SATA III 3.0 Expansion Card Non Raid Expansion Card Low Profile Bracket

Certification:NONE
Origin:CN(Origin)
Model Number:IOPCE582424I
Type:Add On Cards
Interface Type:PCI Express
Color:Black
Number of Ports:24 Ports
Chipset:JMB
Transfer Rate:6Gbs

PCIe Gen3 X14 to 24 Ports 6G SATA III 3.0 Expansion Card Non Raid Expansion Card Low Profile Bracket
Supports up to two lane of PCI Express.
Complies with for PCI Express Base Specification Revision 3.1a.
Compliant with for Serial ATA Port Multiplier Spec. Revision 1.2
Compliant with for Serial ATA Port Selector Spec. Revision 1.0
Compliant with for Serial ATA PHY Electrical Spec. Revision 1.0
Complies with for SATA Specification Revision 3.2
Supports PCIe link layer power saving mode.
Supports 24-port 6Gb/s SATA III interface.
Supports Port Multiplier
Supports command-based and FIS-based for Port Multiplier.
Supports AHCI mode and IDE programming interface.
Supports Native Command Queue (NCQ).
Supports SATA link power saving mode (partial and slumber)
Supports SATA plug-in detection capable.
Supports drive power control and staggered spin-up.
Supports SATA Partial / Slumber power management state.
Note:Don't support system boot disk
size:16.8x6.4cm
Material:ABS
colour:black
Package Contents:
1 * SATA expansion card
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
