HDMI-compatible Splitter Cable To Vga Adapter Divider One Minute Two Strip 4K 30HZ 1 Minute Two Screen Multiple Display

Certification:NONE
Origin:CN(Origin)
Resolution:4K*2K
Thread length:0.5

[Product Introduction]
This HDMI high-definition distributor is a high-definition audio and video distributor that connects the HDMI signal source with the input of the distributor by using an HDMI cable (which needs to be purchased separately and the length does not exceed the transmission distance), so that one HDMI input port can be allocated two HDMI output ports. It can distribute the HDMI signals of set-top box, DVD player, D-VHS player and other HDTV devices into two consistent and synchronous HDMI signal outputs. Users can connect the output signal to HD projector, DLP, LCD, HD TV and other HD display devices at the same time.
[Product performance]
This HDMI distributor has many features and excellent performance. In these features, you will find:
1. 1x2 4K*2K HDMI high-definition splitter It is a flexible hub suitable for a variety of displays. Through the stacking method, the number of HDMI output ports can be significantly increased, and the connection between the splitter and the splitter can be supported. If two or more HDMI splitters are connected, a larger splitter can be formed.
2. It has the ability of signal buffer and amplification;
3. Long-distance transmission (extended) of more than 15 meters can be achieved through serial connection;
4. Support 480p, 576p, 720p, 1080i, 1080p, 4K * 2K resolution;
5. Support 3D HD video with and clear HDTV resolution up to 4K*2K;
6. Easily connect to multi-channel audio and video receiving equipment;
7. The pixels of the output image are up to 2160 lines, conforming to HDMI1.4 standard, fully compatible with HDCP, fully supporting HDMI1.4, supporting 3D, supporting CEC and fully compatible with HDCP1.3;;
8. Fast installation, simple operation, plug and play, fashionable design, exquisite and compact, easy to carry.
Technical Specifications
1. Video amplifier bandwidth: 2.5 Gbps;
2. Input video signal level: 1.2 volts p-p;
3. Input DDC signal level: 5 volts P-P (TTL);
4. Single channel connection signal range: 3840 * 2160;
5. Video input/output interface: HDMI Type A, 19-pin female
6. Support 30/36-bit dark color, signal timing reorganization and Blu-ray DVD24/50/60fs/HD-DVD/xvYcc.
7. Support audio format: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/DOLBY-AC3/DSD
8. Power supply: 5V DC, power consumption: 5W
