M.2 SSD NVMe M Key + SATA B Key M.2 NGFF PCIE to M2 Adapter Riser PCI Express 3.0 Controller with Low Profile Bracket Heatsink
- M.2 SSD NVMe M Key + SATA B Key M.2 NGFF PCIE to M2 Adapter Riser PCI Express 3.0 Controller with Low Profile Bracket Heatsink
+
+
Overview
Reviews
Interface Type:PCI Express
Package:Yes
Model Number:AC3694
Product name:pcie to m2 adapter
Bus Type:PCI Express 3.0 x4 M.2 Adapter
Support:compatible with PCI-E X4/8/16X Slot
Support m.2:B-Key M.2 NGFF + M-Key M.2 NVME
Support Size:Support the 2230,2242,2260,2280,22110 Type M.2 SSD
Feature 1:ssd m2
Feature 2:ssd pcie
Feature 3:ssd pci-e
Feature 4:m.2 pcie
Feature 5:pcie ssd adapter
M.2 SSD NVMe M Key + SATA B Key M.2 NGFF PCIE to M2 Adapter Riser PCI Express 3.0 Controller with Low Profile Bracket Heatsink
About Description:
Specification
1. Supports one M.2 PCIe (NVMe or AHCI) SSD and a second M.2 SATA 6Gbps SSD simultaneously.
2. Supports M.2 form factors 2230, 2242, 2260 ,2280 and 22110.
3. Converts one M.2 (M Key) interface to PCIE 3.0 x4 interface (PCIE 2.0 Compatible).
4. Converts one M.2 (B Key) interface to SATA 6Gbps interface (SATA connection required). No drivers required.
5. Booting possible from M.2 NVMe SSD with compatible motherboards with supported BIOS.
6. For Intel 9 series and above chipset motherboards support booting from PCIE.
7. This adapter card is a passive device so OS and System compatibility solely depends on SSD model used.
8. Low profile bracket, SATA Cable and complete tool kit included for an effortless install.
Warm Tips:
1. For installing the adapter card an empty PCIE 3.0 or 2.0 spec X4 slot should be available in the motherboard.
2. For installing SATA M.2 SSD, an empty SATA port should be available in the motherboard and the provided SATA cable should be used to connect the card to the motherboard SATA ports.
3. Booting from PCIe SSDs depends on specific motherboard model, BIOS version and the Operating System used.
4. Please check system and OS compatibility with the SSD model.
You'll receive:
1 x PCB Adapter
2 x Heatsink
2 x Metal Bracket(High and Low Profile Bracket)
1 x Screw Driver
1 x User Manual
2 x Screw and Nut
1 x SATA Cable
Please check pictures for more details.
Package:Yes
Model Number:AC3694
Product name:pcie to m2 adapter
Bus Type:PCI Express 3.0 x4 M.2 Adapter
Support:compatible with PCI-E X4/8/16X Slot
Support m.2:B-Key M.2 NGFF + M-Key M.2 NVME
Support Size:Support the 2230,2242,2260,2280,22110 Type M.2 SSD
Feature 1:ssd m2
Feature 2:ssd pcie
Feature 3:ssd pci-e
Feature 4:m.2 pcie
Feature 5:pcie ssd adapter
M.2 SSD NVMe M Key + SATA B Key M.2 NGFF PCIE to M2 Adapter Riser PCI Express 3.0 Controller with Low Profile Bracket Heatsink
About Description:
Specification
1. Supports one M.2 PCIe (NVMe or AHCI) SSD and a second M.2 SATA 6Gbps SSD simultaneously.
2. Supports M.2 form factors 2230, 2242, 2260 ,2280 and 22110.
3. Converts one M.2 (M Key) interface to PCIE 3.0 x4 interface (PCIE 2.0 Compatible).
4. Converts one M.2 (B Key) interface to SATA 6Gbps interface (SATA connection required). No drivers required.
5. Booting possible from M.2 NVMe SSD with compatible motherboards with supported BIOS.
6. For Intel 9 series and above chipset motherboards support booting from PCIE.
7. This adapter card is a passive device so OS and System compatibility solely depends on SSD model used.
8. Low profile bracket, SATA Cable and complete tool kit included for an effortless install.
Warm Tips:
1. For installing the adapter card an empty PCIE 3.0 or 2.0 spec X4 slot should be available in the motherboard.
2. For installing SATA M.2 SSD, an empty SATA port should be available in the motherboard and the provided SATA cable should be used to connect the card to the motherboard SATA ports.
3. Booting from PCIe SSDs depends on specific motherboard model, BIOS version and the Operating System used.
4. Please check system and OS compatibility with the SSD model.
You'll receive:
1 x PCB Adapter
2 x Heatsink
2 x Metal Bracket(High and Low Profile Bracket)
1 x Screw Driver
1 x User Manual
2 x Screw and Nut
1 x SATA Cable
Please check pictures for more details.
