QINDIAN Add On Cards HDD/SSD/SATA Raid Controller/Card M2 to SATA M.2 SATA Card Port Multiplier SATA 3 B+M Key M.2 Adapter Cable

Interface Type:PCI Express
Package:Yes
Model Number:AC4034
Product name:M.2 to 2-port SATA3 Raid Adapter
Main Chipset:ASMedia 1061R
Feature 1:raid controller card
Feature 2:sata raid card
Feature 3:ssd raid card
Feature 4:raid card
Feature 5:sata raid controller
Feature 6:hdd raid card
Feature 7:m2 to sata adapter
Feature 8:m.2 sata adapter

QINDIAN Add On Cards HDD/SSD/SATA Raid Controller/Card M2 to SATA M.2 SATA Card Port Multiplier SATA 3 B+M Key M.2 Adapter Cable
About Description:
Features:
1-Lane M.2 PCI-Express 2.0 interface (B + M Key).
Support communication speed of 2.5Gbps and 5.0Gbps.
Compliant with Bus Master Programming interface for IDE ATA Controllers Revision 1.0.
Compliant with Serial ATA AHCI (Advanced Host Controller Interface) Specification Rev 1.3.
Support Message Signaled Interrupt(MSI).
Serial ATA Revision 3.2.
Support communication speed of 6.0Gbps,3.0Gbps,1.5Gbps.
Support programmable transmitter signal levels.
Supports 1i/1m/2i/2m/3i SATA PHY.
Supports Native Command Queuing (NCQ)
Supports Port Multiplier command based switching.
Supports RAID0, RAID1, SPAN
Note: Not Supported RAID on PM
Supports Hot Plugging on SATA port
Supports automatic rebuild
Supports S.M.A.R.T feature
Windows built-in driver
Main Chipset: ASMedia 1061R
System Requirements:
Windows Server 2008,2012,2016
Windows Vista, 7, 8,8.1,10
Linux 2.6.20 and above
Mac OS 10.3 or later version
You'll receive:
1 x M.2 to 2-port SATA3 Raid Adapter
1 x User Manual
1 x Driver CD
2 x SATA Cable
Please check pictures for more details.
