CSR8675 Amplifier DAC Decoder Board Lossless Bluetooth 5.0 Amplifier Board with Op Amp JRC5532

Type:Desktop
DSD Sampling Frequencies:2.8224 MHz (DSD64)
Certification:NONE
Inputs:USB Type-B
PCM Sampling Frequencies:48 kHz
Material:Plastic
Origin:CN(Origin)
Outputs:6.5 mm
PCM Word Length:24-bit
Product Name:Decoding Lossless Bluetooth 5.0 Board
Chip:CSR8675 5.0 chip
Bluetooth:5.0
Receiving distance:about 10 meters
Voltage:DC 12V (inside outside)
PCB size:75.5x66.5x19mm (without antenna)
Colour:black

CSR8675 Amplifier DAC Decoder Board Lossless Bluetooth 5.0 Amplifier Board with Op Amp JRC5532
Bluetooth uses imported CSR8675 5.0 chip, DAC uses imported PCM5102, and op amp uses JRC5532 (other dual op amps can be ly replaced).
The electrolytic capacitor adopts imported gold-letter Panasonic 220UF/25V electrolytic capacitor to ensure strong and continuous power support.
High-precision chip resistors are selected for the resistors to ensure a good signal-to-noise ratio of the whole machine.
The PCB adopts 1.6mm thick double-sided board, 2.0 oz copper thickness, and full tin spraying process to ensure good passing performance of large and small currents. First-class PCB quality.
Product Name: Decoding Lossless Bluetooth 5.0 Board
Chip: CSR8675 5.0 chip
Bluetooth: 5.0
Receiving distance: about 10 meters
Voltage: DC 12V (inside + outside)
PCB size: 75.5x66.5x19mm (without antenna)
Colour: black
Material: PCB+metal
Package Contents:
1 * Decoder board
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
