    Audio Extractor & HDMI Video Switch UHD HDMI to HDMI+Audio (SPDIF+LCH/RCH) Audio Splitter 4K 2 In 1 Out HDMI Switch Video Audio Splitter - Extract Audio while Switching

    Be the first to review this product...
    • TWO HDMI input convert to one HDMI+Audio(SPDIF+LCH/RCH)output
    • Support HDMI2.0 version HDCP2.3 version
    • Support 4KX2K Input Resolution up to 2160P 60Hz(3840x2160@60Hz)
    • Support HDR 3D CEC ARC
    • Support deep color 24bit,30bit,36bit
    • Support Ps4 pro Blue-Ray HD-DVD24/50/60fs/Ycbcr/YUV/RGB
    • Digital audio format,as DTS-HD/Dolby-trueHD/LPCM5.1/Dolby-AC3/DSD
    • HDMI to achieve the synchronization of audio signal separation.There are PASS/2.0CH/5.1CH three kinds of audio modeoptions
    • Support input up to 8metres AWG24 HDMI standard cable length, output up to 5metres AWG24 cabl elength(2160P/60Hz)
    • No loss of quality,Installs in minutes
    +
    +
    Overview
    Specs
    Reviews
    This UHD 2 TO 1 converter allows the UHD Source to be connected to a single UHD Dispaly and adds extra features a LCH/RCH and SPDIF audio output port Supports HDM 2.0 version.HDCP23 version.The Converter can also be placed at the end of a long HDMI cable to regenerate the HDMI signal.



    FEATURES

    TWO HDMI input convert to one HDMI+Audio(SPDIF+LCH/RCH)output

    Support HDMI2.0 version HDCP2.3 version

    Support 4KX2K Input Resolution up to 2160P 60Hz(3840x2160@60Hz)

    Support HDR 3D CEC ARC

    Support deep color 24bit,30bit,36bit

    Support Ps4 pro Blue-Ray HD-DVD24/50/60fs/Ycbcr/YUV/RGB

    Digital audio format,as DTS-HD/Dolby-trueHD/LPCM5.1/Dolby-AC3/DSD

    HDMI to achieve the synchronization of audio signal separation.There are PASS/2.0CH/5.1CH three kinds of audio modeoptions

    Support input up to 8metres AWG24 HDMI standard cable length, output up to 5metres AWG24 cabl elength(2160P/60Hz)

    No loss of quality,Installs in minutes



    SPECIFICATIONS:

    HDMI UHD resolution....................................24/25/30/50/60fs/2160p

    Support video color format....................................24bit/30bit/36bit

    Support audio format..DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD

    Max bandwidth........600MHZ

    Max baud rate............................................................18Gb

    Input/Output TMDS signal..........................0.5~1.5Volts p-p(TTL)

    Input/Output DDC signal...........5Volts p-p(TTL)

    2160p Input/OUTPUTcable distance.......=5m AWG24 HDMI standard cable

    Max working current.........350mA

    Operating Temperature range.........(-15 to +55°?)

    Operating Humidity range......................5 to 90%RH (No Condensation)

    Dimension(LxWxH).........146x615x17(mm)

    Weight.........195g



    Operating and Connecting:

    1.Connect the HDMI cable from the HDMsource device tothe HDM converter input port.

    2.Connect the HDMI cable from the monitor(monitor or projector)to the HDMI switcher output port.

    3.The optical output is connected to the digital audio poweramplifier input,and the L/Routput is connected to the analog power amplifier input

    4.Connect the converter with the DC5.5 head of the USB power cable and connect the UsB head to the USB port that can supply power.



    Notes:

    Pls use the machine as the instruction listed to keep the long use lifetime of the machine.

    1.The machine should be placed at the spot far from the Damp High-Temperature,Dusty,Erosiveandoxidativeenvironment.

    2.All parts will be free from the strong shake,hit,fall.

    3.Pls do not open the cover and do not touch the inside parts.
