2/4 Ports KVM Switcher 4 IN 1 Out USB Switch Splitter for Sharing Monitor Keyboard Mouse Adaptive support EDID/HDCP

2/4 Ports KVM Switcher 4 IN 1 Out USB Switch Splitter for Sharing Monitor Keyboard Mouse Adaptive support EDID/HDCP

1.Description

2 ports KVM switch; 2 groups of high-definition video source and USB interface realize freely switch. Adaptive EDID/HDCP decryption. The equipment has excellent image processing and transmission capacity, make the output signal is more smooth and steady, is a reliable, high performance and efficient way of USB switch. Suitable for office, computer room, monitoring host, etc. And switch freely by hotkey.

2.Features

The 2 routes of high-definition video source and USB interface implementation freely switch;

Support video resolution up to  3840*2160 @30Hz

Compliance with 1.4 standard;

Adaptive EDID/HDCP decryption, able to adapt to a variety of complex application environment;

It can be switched by hotkey mode and host key mode, which is convenient and quick;

HDCP 1.4 standard - high-bandwidth digital content protection technology;

High compatibility, can auto-match source and display device;

Built-in automatic adjustment system, make the image smooth, clear and stable;

Built-in ESD protection system;

Simple to install, plug and play;

3.Specifications

Parameter

Description

Video

Standards

1.4HDCP 1.4

Maximum pixel clock

340MHz

Maximum data rate

10Gbps

Resolution range

Up to 4Kx2K@30Hz, 3D, 1920*1080@60Hz

Connector

-A Interface

Cable Range

5M( Resolution: 1920*1080@60Hz)

USB

Interface protocols

USB2.0

PC input interface type

USB-B

USB-A
