6 Port POE Switch Gigabit Ethernet Network Switch Standardized RJ45 Port IEEE 802.3 af/at for POE cameras

POE Switch supply power to 5 classes Ethernet wireless access point (AP) and network surveillance cameras

1000mbps switch have Port 1 to port 4 compatible with IEEE802.3af/at

standard power

Supply (Maximum power of each port is 30W)

4x 10/100 /1000Mbps automatic adjustment RJ45 ports ethernet switch

Meets the standards of the IEEE 802.3 /IEEE

802.3u/IEEE 802.3z and IEEE 802.3ab

Flow Control Type: Full duplex adopts IEEE 802.3x standard, half duplex adopts back pressure standard

Auto-flip ports (Auto MDI/MDIX)

Network port has lighting-proof function (AC power port: differential mode +/-2kV, common mode +/-4kV)

Maximum PoE Power: 65W

Store-and-forward architecture, 192K forwarding memory

All ports support wire-speed switching, frame size

within the range of 64 to 1536 can achieve wire-speed

Wall-mounted design, easy to install and use

Automatic adjustment, plug and play, no need software and protocol conversion

Ordering Note: Default PoE power supply type is end-span(12, 36 line pair),

mid-span(45, 78 line pair) optional

SFP module isnt include in the accessories, pls order it seperatly

Technical parameter list

Product Name

6-PortS PoE Switch with 4 PoE Ports and 1 Ethernet Uplink and 1 Uplink SFP

Model

HR901-AFG-411S

Connector Type

6 x 10/100/1000M copper cable RJ45 ports( 4 PoE ports + 1 Ethernet Uplink + 1 Uplink SFP Port)

Network Media

10BASE-T: Cat3,4,5 UTP(100 meter) 100BASE-TX: Cat5 or more UTP (100 meter) 1000BASE-TX : Cat6 or more (100 meter)

Bandwidth

12Gbps (non-blocking)

Address Database Size

2K

MTBF

190,000 hours
