KC868-D8 Dimmer Controller Use Manual And Protocol

1.Manual control and wireless remoter control by the same work way

A. Manual control switch for dimmer, 16 ports for input, every 2 ports are brightness+ and brightness- for every channel dimmer.

For example:

Press and hold key 1 of the first dimming lamp, the brightness will increase and gradually increase to the brightest state. Record the current brightness status after you remove hand.

Press and hold key 2 of the first dimming lamp, the brightness will decrease, and gradually reduce to the darkest (off state) state. Record the current brightness status after you remove hand.

Other channel lamp is the same.

If you press the on key (normal speed of the on / off key) manually and quickly, you can turn on the light and turn off the light. (the brightness of the on light is the brightness before turning off the light)

For example:

quickly press the "brightness increase" button of the first way, the first way light is on (the brightness of the light is the brightness before turning off); quickly press the "brightness decrease" button of the first way, the first way light is off;

Quickly press the "brightness increase" button of the second way, the second way light is on (the brightness of the light is the brightness before turning off); quickly press the "brightness decrease" button of the second way, the second way light is off;

Other channel lamp is the same.

B. Remoter control dimming, 16 key wireless remoter, a total of 16 keys, each two keys to  "brightness increase", "brightness decrease" function, press and hold the key, it will continue to change slowly.

For example:

Other channel lamp is the same.
