10G Enhanced SFP+ Media Converter 10GBase-T Ethernet Switch RJ45 to Optical Fiber Optic Transceiver Optical Convert FTTH Tool DC

Product Name

SFP 10GBase-TX to 10GBase-FX Media Converter

Brand Name

Model Number

RTX-10G SFP+ Media Converter

Standards

IEEE802.3 10Base-T

IEEE802.3u 100Base-TX/FX

IEEE802.3ab 1000Base-T

IEEE802.3z 10GBase-SX/LX

IEEE802.3x Flow control

IEEE802.1p QoS

IEEE802.1d Spanning Tree

IEEE802.1q VLAN

Connector Type

1 x RJ45

1 x SFP slot

Ethernet Port(EP)

Connector: RJ45

Data Rate: 10Gbps

Distance: 100Meters

Full-Duplex and Half-Duplex auto-negotiation

UTP Type: UTP-5E or higher level

Fiber Port(FP)

Connector: SFP slot

Data Rate: 10G

Optical wavelength: 850nm/1310nm/1490nm/1550nm

Distance: 550m100km

Processing Type

Store and Forward

Power Supply

Power type: External Power Supply

Input Voltage :AC100V~ 250V

Output Voltage: DC12V

Power Consumption

0.75-3W

Buffer Space

1Mbit

Working Environment

Operating Temperature:  -10 ° ~ 55 ° C

Storage Temperature: -40 ° ~ 70 ° C

Relative Humidity: 5-90% ( no condensation)

Warranty

5 years

Package includes:

1. 10G SFP+ Media Converter*1pcs

2. Power Adapter 12V *1PCS (pls tell us your power adapter , or we'll send default adapter)
