PMS6003 PM2.5 Sensor Laser Particle Sensor Detector Air Quality Tester

Feature:

PMS6003 is a digital universal particle concentration sensor based on the principle of laser scattering. It can continuously collect and calculate the number of suspended particles with different particle sizes in the unit volume, that is, the particle concentration distribution, and then convert it into mass concentration. Interface form output. The sensor can be embedded in various instruments and environmental improvement equipment related to the concentration of suspended particulates in the air, providing it with technically accurate concentration data. PMS6003 uses the latest proprietary technology-dual laser technology, which can achieve dual laser linkage and mutual calibration, thereby extending the service life more than doubled.

Pin Description:

VCC

Power +5V

GND

Power supply-

SET

Set the pin/TTL level @3.3V high or floating to normal operation, low level to sleep state

RXD

Serial receiver pin / TTL Level @3.3V

TXD

Serial transmit pin / TTL level @3.3V

RESET

Module reset signal / TTL level @3.3V, low reset

NC

Parameter

Index

Unit

Particulate matter measurement range

0.3 ~ 1.0; 1.0 ~ 2.5; 2.5 ~ 10

Micrometer (um)

Particle counting efficiency

50% @ 0,3 microns 98% @> = 0.5 microns

Effective range of particulate matter concentration (PM2.5 standard value)

0-500

g / m3

Maximum range of particulate matter concentration (PM2.5 standard value)

> = 1000

g / m3

Particulate matter concentration resolution

1

g / m3

Particulate matter concentration consistency (PM2.5 standard value) *

± 10% @ 100 ~ 500g / m3

± 10 g / m3 @ 0 ~ 100 g / m3

Quasi-volume

0.1

Liter (L)

Single response time

<1
