ECS 945P-A (1.1) LGA 775 Intel 945P ATX Intel Motherboard

OPEN BOX Product Type
  • Intel 945P
  • Pentium D / Pentium 4 HT / Celeron D
  • DDR2 667
Please note that this product is non-returnable and non-refundable.
Specs

Learn more about the ECS (EliteGroup) 945P-A (1.1)

Model
Brand ECS
Model 945P-A (1.1)
Supported CPU
CPU Socket Type CPU Socket TypeLGA 775
CPU Type Pentium D / Pentium 4 HT / Celeron D
FSB 1066/800 MHz
Supported CPU Technologies Hyper-Threading Technology
Chipsets
Chipset ChipsetIntel 945P
South Bridge Intel ICH7
Onboard Video
Onboard Video Chipset Onboard Video ChipsetNone
Memory
Number of Memory Slots 4x240pin
Memory Standard DDR2 667
Maximum Memory Supported 4GB
Channel Supported Channel SupportedDual Channel
Expansion Slots
PCI Express x16 2 x PCI Express x16 slot (Orange : x16 mode, Blue : x4 mode)
PCI Express x1 2 x PCI Express x1
PCI Slots 3 x PCI Slots
Storage Devices
PATA 1 x ATA100 2 Dev. Max
SATA 3Gb/s SATA 3Gb/s4 x SATA 3Gb/s
Onboard Audio
Audio Chipset Audio ChipsetRealtek ALC880
Audio Channels Audio Channels8 Channels
Onboard LAN
LAN Chipset Realtek 8110S
Max LAN Speed 1Gbps
Rear Panel Ports
Back I/O Ports 1 x Optical S/PDIF Out / 2 x PS/2 / 4 x USB 2.0/1.1
PS/2 PS/22
COM 1
LPT 1
USB 1.1/2.0 4 x USB 2.0
S/PDIF Out S/PDIF Out1 x Optical
Audio Ports 5 Ports
Internal I/O Connectors
Onboard USB 4 x USB 2.0
Physical Spec
Form Factor ATX
Dimensions (W x L) 12.0" x 9.6"
Power Pin 24 Pin
Details
Windows Vista Certified for Windows Vista
Additional Information
Date First Available August 21, 2008
