TRENDnet TC-P24C6AS 24-port Cat6A Shielded 1U Patch Panel, 1000BASE-T / 10GBASE-T Support, compatible with cat5e, cat6, cat6a, 110 or Krone type- Type: Others
- Color: Black
- Specifications: Standards:
ANSI/ TIA/ EIA-568-B.2-1
ANSI/ TIA/ EIA-310-D
EN50173-1: 2002
ISO/ IEC 11801 2nd edition: 2002
Interface :
24 x Gigabit T568A/T568B wiring cards for Krone 110 termination
90° angle type
Compatible with 22 to 26 AWG solid wires
50 micron shielded gold plated jack connectors
Electrical Specification:
Dielectric Withstand Voltage: 1000V DC
Current rating: 1.5A at 68° F
Mechanical Specification:
Contact force 99.2g (3.5 oz.)
Plug retention force: 13.3kg (30 lb.)
110/ Krone IDC insertion force: min. 4.5kg (9.9 lb.)
110/ Krone IDC retention force: min. 0.5kg (1.1 lb.)
Operating Temperature: -25° – 50° C (-13° – 122° F)
Operating Humidity: Max. 90% non-condensing
Dimensions:
1U design
440 x 105 x 40mm (17.3 x 4.1 x 1.6 in.)
Weight: 1.6kg (3.5 lb.)
- Model #: TC-P24C6AS
Quick View
TP-Link JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+ (TL-SG2428P)- Switch Type: other
- Format: Desktop
- Standards: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
- Primary Ports: 24 x RJ45 + 4 x SFP
- Model #: SG2428P
Quick View
- $321.99
-
- $266.99 –
- Save: $55.00 (17%)
- Free Shipping
