Onboard Video Chipset: Supported only by CPU with integrated graphic:
1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz 1 2
1x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz 1
Maximum shared memory of 16GB
1. Available for the processor with integrated graphics.
2. Graphics specifications may vary depending on the CPU installed.
Max CPU Cooler Height: Caution: The cover increases the height of the heatsink by 6mm (from 158 to 164mm) and the total width by 3mm (from 125mm to 128mm). Please make sure that your case offers sufficient clearance and that the cover doesn’t make contact with any other components such as PCIe cards!
PCI Express 3.0 x16: 1 x PCI Express 3.0 x16*
* Actual support may vary by CPU.
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
PCI Express 2.0 x16: 1 x PCI Express 2.0 x16*
* Running at x4.
Memory Standard: DDR4 3200 / 3066 / 3000 / 2933 / 2800 / 2667 / 2400 / 2133 / 1866 (by JEDEC)
Max overclocking frequency by A-XMP OC mode:
For Ryzen 5000 G-Series & 4000 G-Series processors
- 1DPC 1R Max speed up to 5100
- 1DPC 2R Max speed up to 4000
- 2DPC 1R Max speed up to 4266
- 2DPC 2R Max speed up to 3600
For Ryzen 5000 Series & 3000 Series processors
- 1DPC 1R Max speed up to 5100
- 1DPC 2R Max speed up to 3866
- 2DPC 1R Max speed up to 4000
- 2DPC 2R Max speed up to 3600
Onboard Video Chipset: Supported only by CPU with integrated graphic
Memory Standard: DDR4 4400(O.C.)/ 3533(O.C.)/ 3466(O.C.)/ 3200(O.C.)/ 3000(O.C.)/ 2800(O.C.)/ 2666/ 2400/ 2133 MHz Un-buffered Memory
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
PCI Express 3.0 x16: 3rd/2nd/1st Gen AMD Ryzen Processors
1 x PCIe 3.0/2.0 x16 (x16 mode)
2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
1 x PCIe 3.0/2.0 x16 (x8 mode)
AMD Athlon with Radeon Vega Graphics Processors
1 x PCIe 3.0/2.0 x16 (x4 mode)
PCI Express 2.0 x16: 1 x PCIe 2.0 x16 (max at x4 mode) *
* PCIE x16_2 will be unavailable when installing M.2 PCIE SSD in M.2_2 socket.
* PCIe x16_2 will run x2 when installing devices in PCIe x1_1 or PCIe x1_2 slots.
* PCIE x16_2 will run x4 when no devices i...
