Compatibility: OS Compatibility: Windows 7, 8, 8.1, 10
Ports Spec: 1 x USB Type-C (24 pin) USB 3.0 Male
1 x USB-C (24 pin) USB Power Delivery only Female
2 x 20 pin DisplayPort Female
1 x RJ-45 Female
1 x USB Type-A (9 pin) USB 3.0 Female
1 x USB Type-A (4 pin) USB 2.0 Female
Specifications: Audio: Yes
Cabling: DisplayPort
Rack-Mountable: Yes
Max Distance: 66 ft.
Maximum Cable Length: 65.6 ft.
Maximum Digital Resolutions: At 7m Up to 4K at 60Hz / At 13m Up to 4K at 30Hz / At 15m Up to 2560 x 1600 at 60Hz / At 20m Up to 1080p
Supported Resolutions: 3840 x 2160 (4K), 2560 x 1600, 1920 x 1200, 1920 x 1080 (1080p), 1280 x 720 (720p)
Wide Screen Supported: Yes
Power Source: AC Adapter Included
Specifications: Hardware
Chipset ID: STDP4320 - VL100
Converter Type: MST Hub
Output Signal: DisplayPort
Ports: 3
Connector(s)
Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B: 3 x DisplayPort (20 pin) Female Output
Performance
Maximum Digital Resolutions: 3840 x 2160 at 30 Hz
Wide Screen Supported: Yes
Supported Resolutions:
Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup.
Average resolution bandwidth allocation
1920 x 1080 (High-definition 1080p) at 60 Hz - 22%
1920 x 1200 at 60 Hz - 30%
2560 x 1440 at 60 Hz - 35%
2560 x 1600 at 60 Hz - 38%
3840 x 2160 (Ultra HD 4K) at 3...
