Package Contents: USB 3.0 to M.2 SATA External SSD Enclosure with UASP
1 x USB 3.0 Cable
1 x SSD screw kit
1 x Mini Screw Driver
1 x Instruction Manual
Specifications: Connector(s):
1 - Drive Connectors: M.2 (PCIe, SATA, M-Key, NGFF)
1 - Host Connectors: USB 3.1 USB Type C (10 pin, Gen 2, 10 Gbps)
Interface: USB 3.1 Gen 2
Bus Type: USB 3.2 Gen 2 10Gbps
Number of Drives: 1
Drive Size: 22 mm - M.2 NVMe
Compatible Drive Types: M.2 (PCIe, NVMe, M-Key, NGFF)
Drive Installation: Fixed
Compatible Drive Types: M.2 SATA (NGFF, B+M-Key)
Supported Drive Height(s):
2230
2242
2260
2280
Chipset ID: Realtek - RTL9210B
1 - LED Indicators: Power & Activity
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.2 Gen 2 - 10 Gbit/s
UASP Support: Yes
TRIM Support: Yes
4Kn Support: Yes
Type and Rate: NVMe (PCIe Gen 3)
Insertion Rating:
USB-C: 10,000 cycles
M.2: 60 Cycles
General Specifications: Fully compatible with M.2 SATA, AHCI and PCIe NVMe based drive...
Specifications: Device Support: SATA III/II/I HDD or SSD or Hybrid
Device Size: 3.5" or 2.5" SATA HDD/SSD/Hybrid
Internal Interface: Standard SATA
External Interface: USB 3.1 Type C
Interface Cable x2:
USB Type-C to Type-C (for system with Type-C port)
USB Type-C to Type-A (for system with Type-A port)
USB cable Length: 30 inches / 800mm each
HD Capacity: Up to 12TB
Material: Aluminum Casing, ABS Tray
AC Adapter Output: 12VDC, 2A.
Specifications: Bus Type USB: 3.1 Gen 2
Chipset ID: ASMedia - ASM1352R
Compatible Drive Types: M.2 (NGFF, B-Key)
Drive Installation: Fixed
Interface: USB 3.1 Gen 2
Number of Drives: 2
Supported Drive Height(s): 2230, 2242, 2260, 2280
General Specifications Not compatible with PCI-Express M.2 SSDs
Maximum Data Transfer Rate: 10 Gbps
MTBF: 35,000
Port Multiplier: Yes
Trim Supported: Yes
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
LED Indicators: 2 - Read / Write (green), 2 - Error / Rebuilt (red)
Specifications: Duplicate or dock a SATA SSD/HDD with fast performance - USB 3.1 (10Gbps) standalone duplicator dock for 2.5" & 3.5" SSD/HDD drives - HDD cloner with fast-speed SSD duplication up to 28GB/min - 2.5in and 3.5in hard drive duplicator and drive dock - Works with both USB-C and USB-A enabled devices w/ two cables included - Dual-bay duplicator dock featuring toaster-style design with drive doors and drive eject buttons - Compatible with Thunderbolt 3 USB-C port - Supports SATA I/I/III (up to 6Gbps)
