Ubiquiti Networks airFiber 60 Xtreme-Range (AF60-XR)

Multi-gigabit, 60 GHz bridge designed to create long-distance links and deliver 5.4 Gbps total throughput (2.7 Gbps duplex) over them.
15+ km link range
2.7 Gbps duplex
5 GHz 800+ Mbps weather-resilient backup radio
(1) GbE and (1) 10G SFP+ port
Precision alignment mount
Integrated GPS & Bluetooth
Note. This product should be purchased in pairs in order to form links.

Overview

Specs

Reviews

Multi-gigabit, 60 GHz bridge designed to create long-distance links and deliver 5.4 Gbps total throughput ( 2.7 Gbps duplex) over them.

It's also equipped with a 5 GHz backup radio for operational redundancy, as well as a Bluetooth radio to simplify setup via the UISP® Mobile app.

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Limited Warranty period (parts): 1 year
Limited Warranty period (labor): 1 year
Read full details

Return Policies

Return for refund within: 30 days

Returns are subject to restocking fees and return shipping fees. Please click here to learn more about restocking fees and return shipping fees.

This item is covered by Newegg.ca's International Order Return Policy. Read full return policy for details.

Frequency Band Frequency Band	RF Operating frequency* 57–71 Ghz * Depends on regulatory region. Channel bandwidth 2160, 1080 MHz Operating channels* 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120 MHz * Depends on regulatory region. Management radio 2400–2483.5 MHz Modulation 16QAM, BPSK, QPSK Polarization Vertically linear Beamwidth Azimuth: 3 dB 1.4° Elevation: 3 dB 1.4° Electrical downtilt 0° Back-Up RF Operating frequency* US/CA Worldwide U-NII-1 5150 - 5250 MHz U-NII-2A 5250 - 5350 MHz U-NII-2C 5470 - 5725 MHz U-NII-3 5725 - 5850 MHz 5150 - 5875 MHz *Depends on regulatory region. Channel bandwidth 20, 40, 80 MHz Modulation BPSK (½), QPSK (½), QPSK (¾), 16QAM (½), 16QAM (¾), 64QAM (2/3), 64QAM (¾), 64QAM (5/6), 256QAM (¾), 256QAM (5/6) Antenna gain 26 dBi Polarization Dual-linear Beamwidth Azimuth: 3 dB 5° Elevation: 3 dB 5° Cross-pol isolation 14 dB Electrical downtilt 0°
LEDs LEDs	Power Flashing white: bootup in progress White: not connected to UISP application Blue: connected to UISP application Ethernet Flashing blue: Ethernet activity GPS Blue: receiving at least (4) GPS satellite signals Link Blue: 5GHz link Blue: 60GHz link
Buttons	Factory reset
LAN Ports LAN Ports	(1) GbE RJ45 port (1) 1/10G SFP+port
Power Supply	Max. power consumption 24W Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only Power supply 48V DC, 0.65A gigabit PoE adapter (Included) Supported voltage range 44–54V DC 22–27V DC

Temperature	-40 to 55° C (-40 to 131° F)
Humidity	5 to 95% noncondensing

Dimensions	779 x 664 x 383 mm (30.7 x 26.1 x 15.1")
Weight	Without mount: 8.6 kg (19 lb) With mount: 13 kg (28.7 lb)
