Kenwood eXcelon Series KFC-XW1000F Shallow-mount 10 4-ohm Subwoofer

Kenwood eXcelon Series KFC-XW1000F Shallow-mount 10 4-ohm Subwoofer
The Kenwood Excelon KFC-XW1000F 10 flat subwoofer produces serious bass output in the hard-to-fit areas of your compact car or truck. The shallow-mount sub measures less than 3-1/2 deep, so you can get creative with your installation.
The carbon-glass fiber cone employs a honeycomb pattern to deliver quick response in demanding conditions without flexing. The beefed-up rubber surround maintains control over the cone, minimizing distortion caused by resonance. A die-cast aluminum basket offers a rock-solid housing with plenty of venting to keep the heat down. The silver-plated push terminals offer convenient connections and provide excellent signal transfer.

KFC-XW1000F Features:
Flat Subwoofer: The Kenwood eXcelon flat subwoofer design is approximately 40% slimmer in height than a standard subwoofer. This makes them ideal for installation in the tightest of spaces such as behind or under the seat of a pickup truck.
Carbon-Glass Fiber Cone: The eXcelon flat woofer uses a carbon-glass fiber honeycomb cone which allows the woofer to be efficient and durable at the same time.
Rubber Surround: The Kenwood woofer features a smooth linear rubber surround for added durability and increased excursion resulting in exceptional deep bass response.
Super Linear Spider: The flat woofer utilizes a super linear spider for maximum control over the woofers linear motion to improve overall sound quality.
Heat Transfer System: The Kenwood woofer features an advanced Heat Transfer System designed specifically for its slim-design to provide proper ventilation to keep the woofer cool.
Aluminum-Cast Basket: The woofer is housed in a cast-aluminum basket for increased rigidity and long-lasting reliability.
Spring Terminals: The flat woofer utilizes a pair of silver-plated spring terminals on one side of the woofer for connection to your amplifiers speaker wiring. The spring terminals will accept up to 10 AWG speaker wire.
Concealing Ring: The eXcelon woofer comes supplied with a removable, rubber concealing ring used to hide the woofers mounting screws for a neat and professional looking installation. The concealing ring increases the top mounting height to 1.

Enclosure Compatibility
Sealed Box Volume: The sealed box size recommended by Kenwood is 0.6 cu/ft.
Vented Box Volume: The vented box size recommended by Kenwood range is 0.6 cu/ft. One 3 diameter x 11 long port should be used with a 0.6 cu/ft enclosure.

KFC-XW1000F highlights:
10 4-ohm shallow-mount subwoofer
carbon-glass fiber composite cone with butyl rubber surround
cast aluminum basket
power range: 50-250 watts RMS
peak power: 1, 000 watts
frequency response: 35-800 Hz
sensitivity: 90 dB
mounting depth: 3-15/16
sealed box volume: 0.6 cu. ft.
ported box volume: 0.6 cu. ft.
warranty: 2 years
Whats in the box:
KFC-XW1000F Manual
One 10 SVC Woofer
Rubber concealing ring (installed)
Self-adhesive foam strip
8 Mounting screws
Kenwood logo sticker for woofer
eXcelon logo sticker for woofer
Cardboard template
Instruction Manual (English/French/Spanish)
Warranty Card
