Z83 TV Box 4G 64G Windows 10 Atom x5-Z8350 4K 3D Mini PC 1000M LAN Bluetooth 4.0 2.4G 5.8G Wifi Miracast Set Top Box

Item

Description

Z83

Dimension

119.5*119.5*24mm

System Config.

CPU

Atom x5-Z8300 Processor (2M Cache, up to 1.84 GHz) 64Bit

Processor Graphics

HD Graphics

RAM

DDR3 4GB

System Disk

Windows(C:) 64GB

Bluetooth

BT 4.0

Expand Memory

Card (Support 128GB)

Antenna

Built-in antenna for WIFI

Communication

Ethernet

1000M LAN

WIFI

IEEE 802.11a/b/g/n, 2.4G+5.8G

IEEE 802.11a/b/g/n, WiFi compliant

2.400 GHz ~ 2.497 GHz (2.4 GHz ISM Band)

4.900 GHz ~ 5.845 GHz (5.0 GHz ISM Band)

Button & Ports

Button

1*Power Button

USB3.0

1* Standard USB Port

USB2.0

2* Standard USB Port

DC-in

1*DC in Port

HDMI

1*HDMI A Type

1*VGA Port

Power LED

1* power LED with two - color

RJ45

1*RJ45 (1000Mbps network connection)

TF Card Slot

1* card slot

Headphone microphone

1*Headphone microphone jack

Power management

Adapter

DC12V 2A(100-240V,50/60Hz)

Software Config.

OS

Windows 10

Language

Multi -language

Keyboard

Qwerty keyboard

Advanced Technologies

64-bit

Yes

Identity Protection Technology

Yes

Work Environment

5C-- 35C,30%--90% Humidity

Storage Environment

20C -- 60C 10%--90% Humidity

Package Listing

1 * Z83 V MINI PC

1 * Power Adapter

1 * HDMI Cable

1 * Bracket

4 * Screw

1 * English User Guide
