SICK VS/VE18-3P3412 Through-beam Photoelectric Sensor ,PNP,New

Shop All Sick Products | Visit B-IN Electronics Store

SICK VS/VE18-3P3412 Through-beam Photoelectric Sensor ,PNP,New

SICK VS/VE18-3P3412 Through-beam Photoelectric Sensor ,PNP,New

Overview

Specs

Reviews

FEATURES Sensor/ detection principle Through-beam photoelectric sensor Dimensions (W x H x D) 60.6 mm Housing design (light emission) Cylindrical, angled Sensing range max. 0 m... 20 m Sensing range 0 m... 14 m Type of light Infrared light Light source LED Adjustment Potentiometer MECHANICS/ELECTRONICS Supply voltage 10 V DC... 30 V DC Ripple = 10 % Power consumption = 30 mA 1) Switching output PNP Switching mode Dark switching Response time = 2 ms 2) Connection type Cable, 2 m 3) Cable material PVC Conductor cross-section 0.14 mm² Cable diameter Ø 3.1 mm Housing material Metal, Brass nickel-plated, plastic Optics material Plastic, PMMA Enclosure rating IP67 Ambient operating temperature –25 °C.

.. +70 °C Ambient storage temperature –25 °C... +70 °C UL File No. NMFT2. E175606
