Fans:1
PFC Type:Active
Number of SATA Ports:3
Graphics Card 12V Pin Number:2 x6 pin
D-type Bus Number:2
CPU Power Connector:8 pin
Package:Yes
Interface Type:20 + 4Pin
Application:Desktop,Server
Model Number:350w
Input Voltage:164v-264v
Modular:Non-Modular
80 PLUS Certification:Other Certification
Origin:Mainland China
Certification:CE,FCC,KC
Specification:
1: Power supply size: 150*140*83
2: Power standard: ATX 12V
3: Applicable to CPU range: AMD, Intel
4: PFC type: passive PFC
5: Maximum power: 500W
6: Input voltage: 164-264V
7:+ 3.3V output current 15A
+ 5V output current 15A
+ 12V1 output current 45A
- 12V output current 0.3A
+ 5Vsb output current 2.5A
8: Support wide voltage: Yes
9: Support temperature control PWM: Yes
10: Certification: CB, CCC, FCC, Class, CE, ROHS
11: Product weight: 1000g
12: Support power: 20P/24Pin motherboard
13: Power Output Design: Multiplex + 12V
14:IDE interface: 3
15: SATA interface: 2
16: CPU interface: 4 + 4pin*1
17: Video card interface: (6PIN + 2)* 1
