8 Port Gigabit Network Switch Gigabit Ethernet Network Desktop Switch 20Gbps for IP Camera Wireless AP EU UK US Plug

Description:

This 8+2 POE Switch features 8 Ethernet Port 2 Up link Ethernet Port 20Gbps and adopts high backplane bandwidth design, has extremely fast data processing capability to improve smooth data transmission. It provides easier installation way for POE devices, such as IP cameras, wireless AP, network telephone transmission, intelligent house and home system, ITS, high-speed way supervisory, security protection system, TV medical treatment, long-distance broadcast television transmission system, etc.

Features:

Complies with the IEEE 802.3af/at standard and automatically detects and identifies PD devices that comply with the IEEE 802.3af/at standard. It can supply power to a single port up to 30W.

8 Ethernet Port and 2 Uplink Ethernet Port allows to connect with different devices, one button to achieve intelligent run.

The max transmission speed up to 20Gbps.

Supports MDI/MDIX auto-flip on each port.

Features with fanless, natural cooling, small, compact and quiet design, suitable for desktop or wall.

Strong compatibility, no burning equipment, high-speed transmission, no data loss, flexible expansion.

Plug and play, easy installation, no configuration required.

Specification:

Item name: 8+2 POE Switch

Model: ZWD-8+2BZKN-X

POE port: Port 1-8 supports IEEE 802.3af/at (15.4w /30w) network power supply

SFP port: Not support

POE port output power: 15.4W/30W IEEE802.3af/at

POE electricity transmission wire core: 1/2+3/6- wire core

Port description: 8 gigabit Ethernet power supply ports, 2 gigabit upper Ethernet ports

POE connection standard: IEEE802.3af/IEEE802.3at

POE power transmission distance: 100m

Package list:
