Fan Specification
Fan Dimensions 120*120*25mm Fan Blade Quantity 7PCS Rated Voltage DC 12V
Material PBT B. RoHS 2.0 Cable Length 400mm Working Voltage DC 6- 13.2V
Bearing Type Hydraulic bearing Connector/PWM FAN 4pin ARGB 3pin Start Voltage 6V
RPM 800-2000RPM Lighting mode ARGB internal 8PCS
Rated Current Fan: 0.25A LED 0.35A
Air Flow 62.82CFM Quantity of fans 3PCS Locked Current /
Air Pressure 1.89 mmH2O Noise 32dBA Fan Life 40000H
Radiator Specification
Water pump Radiator Water pipe
Dimensions 70*83*53mm Dimensions 397*120*27 Tubing Length 400±10mm
Material PPS Material aluminium Material rubber
RPM 2300RPM±10% Water channel 12PCS Lighting /
Bearing Type Sleeve bearing Noise 26.9 dBA
Connector 2510 Dual AURA 5V 3-pin
Product Secification
Wide Compatibility
Intel LGA 1700/1200/2066/2011-3/2011/1156/1155/1151/1150, AMD
AM5/AM4/AM3+/AM3/AM2+/FM2+/FM2. (Note: No AMD backplate in the package, The AMD must be installed with the original bracket of the motherboard)
Single Product Dimension 397*120*52mm
Retail Gross Weight 2.25 kg
