2U Server CPU Cooler Heatsink Cooling Fan For Intel Xeon LGA 1155 1156 1150 1151 Industrial computer workstation Active Cooling

xlmodel]-[custom]-[51195]

Product Description

2U Server Workstation Industrial Active cooling CPU cooler

Brand Name:CPU Socket: Intel LGA 115X (1150 1151 1155 1156)Application platform:Intel  Core i7-2600, i5-2500 series ,Intel Core i3& i5,Xeon  Processor 3400 SeriesMounting hole distance:75mm x 75mmHeatsink Material:Copper Base + Copper finHeatsink processing technology:Copper base+copper fin ReflowFull Size :89x89x65mmBottom Size:42x42x3.5mmNet Weight:648g

Thermal conductive materials:AD66 (Thermal conductivity: > 4.0W/m-k)

Cooling fan Specifications:Dimension:60mm x 60mm x 25mm (6025)Bearing Type:Dual Ball BearingRated Voltage:12VSpeed Reference:5000RPMAir flow:40.4CFMNoise:41dBALife:70000hConnection:4pin with PWMPacking list:1.Server CPU COOLER * 12.Bracket *1

NOTE:

1.Pls be sure that this Cooler can fit to your CPU model, if can't sure, pls contact us.2.This  Cooler is prefer to Server and Industrial Personal Computer, big noise,  we don't recommand to use it on personal computer.3.The fan is 4pin  with PWM and can condition the speed according to the CPU temperature  automatically.The default fan speed model is different in per  motherboard. (mute,standard,full-speed mode) , if you want mute mode,  pls revise the fan speed model in BIOS, don't think that it has only one  speed mode.4.When you mounting radiator, pls don't turn the singal  screw tightly at once, should fix the four sets screw on it then turn  them tight one by one slowly. (make sure the CPU  can contact the  radiator totally and keep it balance don't make it crushed)
