Product ParametersRadiator Material: Aluminum
Radiator Dimensions: 394* 119.2* 27.2mm(360); 276.8* 119.2* 27.2mm(240)
Fan Rated Voltage: DC 12V
Fan Dimensions: 120* 120* 25mm
Fan Speed: 700- 1800rpm(±10%)
Fan Air Flow: 26.1- 66.81CF M(each)
Fan Life Span: 40,000hours @25°C
Fan Noise Level: 20.55-37.2Dba(max)
Fan Bearing: Hydraulic
Fan Connector: 4 Pin PWM
Pump Dimensions: 80.3* 71*48mm
Pump Noise Level: < 30Dba
Pump Speed: 2600rpm(±10%)
Pump Working Voltage: DC 12V
Pump Power Consumption: 3.6W
Purchase instruction1. Please do not disassemble the equipment and replace the water cooling
liquid by yourself,the wrong operation will cause the irreparable harm;
2. Please do not bend water cooling tube hard;
3. Please choose the appropriate screw to install the water blocks mounting
angle;
4. When installing water blocks, need diagonal installation to fit the screws;
5. In case of upgrading to the appearance and structureno further notice,
the real object shall prevail.
