Physical Characteristics | |
Dimensions (H x W x D): | 7.34 x 4.82 x 2.93in. (18.65 x 12.25 x 7.43cm) |
Weight: (including LiON battery) | 12.56oz (356g) |
Power Requirements: | 4.5 - 14VDC |
Stand-by Current: | 50mA |
Power Sources: | Depending on host:
|
Color: | Twilight Black/Yellow |
Performance Characteristics | |
Scanner Type: | Retrocollective |
Light Source: | 650nm visible laser diode |
Scan Repetition: | 36 scans per second typical |
Minimum element width: | 7.5 mil / 0.191mm |
Nominal working distance: | See decode zone |
Print contrast: | 25% minimum reflective difference |
Roll (Tilt): | ± 10 degrees from normal |
Pitch: | ± 65 degrees from normal |
Skew (Yaw): | ± 60 degrees from normal |
Decode capability: | UPC/EAN, UPC/EAN with Supplementals, GS1-128 (formerly UCC/EAN 128), JAN 8 & 13, Code 39, Code 39 Full ASCII, Code 39 Trioptic, Code 128, Code 128 Full ASCII, Codabar (NW7), Interleaved 2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11, Code 32, Bookland EAN, IATA, GS1DataBar (formerly RSS) |
Interfaces supported: | RS232, Keyboard Wedge, Wand Emulation, Scanner Emulation, IBM 468X/469X, USB and Synapse |
