XPG SX8200 Pro Series: 512GB Internal Solid State Drive PCIe Gen3x4 M.2 2280

The SX8200 Pro M.2 2280 SSD is XPG's fastest SSD to date and is designed for avid PC enthusiasts, gamers, and overclockers.
It features an ultra-fast PCIe Gen3x4 interface that offers peak read/write speeds of 3100/2300MB per second, outpacing SATA 6Gb/s by a wide margin. Supporting NVMe 1.3, the SX8200 Pro delivers excellent random read/write performance and multi-tasking capabilities.

With intelligent SLC caching and a DRAM cache buffer, the SX8200 Pro can accelerate sequential and 4K random read/write speeds to shorten system response time, making it especially suitable for multimedia editing and gaming.

Built with 3D NAND Flash the SX8200 Pro comes with 512GB Capacity, offers higher efficiency, and is more reliable than 2D SSDs. Thanks to the support of data protection technologies, it also features a high TBW and excellent durability to meet the demands of various applications.

The SX8200 Pro supports LDPC (Low-Density Parity-Check) error correcting code technology to detect and fix a wider range of data errors for more accurate data transfers and a longer SSD lifespan.

Supporting E2E (End-to-End) Data Protection and RAID Engine, the SX8200 Pro ensures data safety, integrity, and delivers an extended lifespan.

The SX8200 Pro box has a sleek black XPG heatsink with pre-applied thermal compound inside for easy DIY. With or without heatsink: the choice is yours, as the SX6000 looks great in builds either way.

SPECIFICATIONS:
Capacities: 512GB
NAND Flash: 3D TLC
Interface: PCIe Gen3x4
Form Factor: M.2 2280
MTBF: 2,000,000 hours
Power Consumption: 0.33W Active (Typical); 0.14W Slumber (Typical) (*measured by power meter)
Performance (Max): Read 3100MBps; Write 2300MBps
Operating Temperature: 0deg. C~70deg. C
Storage Temperature: -40deg. C~85deg. C
Shock Resistance: 1500G/0.5ms
Dimensions (L x W x T): 22 x 80 x 3.5mm
Weight: 8g
Certifications: RoHS, CE, FCC, BSMI, VCCI, KC
Warranty: 5-year limited
